JUnit Processing and Visualization

Testkube provides comprehensive support for processing and visualizing JUnit XML reports generated during Test Workflows.
This page explains how Testkube handles these reports and presents the information to users.

JUnit Report Extraction

Testkube automatically scans all artifacts for .xml files that are valid JUnit XML reports.
It then parses their contents to make them available for various reporting and visualization features. Read more.

Artifact Collection

To ensure that your JUnit reports are processed, you need to collect them as artifacts.
For detailed information on artifact collection in Test Workflows, please refer to our Test Workflows Artifacts page.

Visualization Features

Testkube provides multiple ways to visualize and interact with the processed JUnit reports:

1. Execution Overview Tab

On the Overview tab of an Execution page, you'll find a new section dedicated to JUnit reports. This section is located below the execution flowchart and provides:

• A summary of all processed JUnit reports
• The overall status of the tests
• Immediate visibility of any errors and their associated logs

This at-a-glance view allows for quick assessment of test results and easy identification of any issues that require attention.

2. Reports Tab

For a more detailed examination of your JUnit reports, navigate to the Reports tab of the execution. Here, you'll find:

• A comprehensive view of all processed reports
• A search bar for filtering test suites and test cases
• Options to filter results by "passed" or "failed" status

This detailed view allows for in-depth analysis of test results and easy navigation through large sets of test data.

Benefits of JUnit Report Visualization

The enhanced visualization of JUnit reports in Testkube offers several advantages:

1. Quick Overview: Easily assess the overall health of your tests from the Execution Overview tab.
2. Detailed Analysis: Dive deep into test results using the comprehensive Reports tab.
3. Efficient Troubleshooting: Quickly identify and focus on failed tests or error messages.
4. Improved Workflow: Seamlessly integrate JUnit report analysis into your testing and development process.

By leveraging these visualization features, teams can more effectively monitor test outcomes, identify issues, and maintain the quality of their software throughout the development lifecycle.

Creating JUnit Reports

See the examples below for how to create JUnit reports with some of the most common functional testing tools.

info

Always make sure that the generated reports are also included in the corresponding artifacts property for Testkube to find and process them as described above.

Playwright

Add the --reporter=junit argument:

npx playwright test --reporter=junit

Read more in the Playwright Docs.

Postman

Add the junit reporter to the -r argument and specify the output file with --reporter-junit-export:

newman run my-collection.json -r cli,junit --reporter-junit-export /data/artifacts/junit-report.xml

Read more in the Newman Docs

Cypress

Add the --reporter and --reporter-options arguments:

cypress run --reporter junit --reporter-options "mochaFile=results/my-test-output-[hash].xml"

Read more in the Cypress Docs.

Pytest

Add the --junit-xml argument:

pytest tests --junit-xml=/data/artifacts/pytest-report.xml

Read more in the Pytest docs.

JUnit / TestNG with Maven

Make sure you have the surefire plugin added to your pom.xml file:

    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-surefire-plugin</artifactId>
                <version>3.5.0</version>
            </plugin>

            ...
        </plugins>
    </build>

When you run the test goal the corresponding junit xml files will be generated into the target/surefire-reports folder:

mvn test

Read more in the Surefire Plugin docs

Go

Install the go-junit-report tool to convert Go test output to JUnit format:

go install github.com/jstemmer/go-junit-report/v2@latest

Run your tests and pipe the output through go-junit-report to generate the JUnit XML file:

go test -v 2>&1 ./... | go-junit-report -iocopy -set-exit-code -out /data/artifacts/junit-report.xml

The flags used above:

• -iocopy: Copies stdin to stdout, useful for seeing test output in real-time
• -set-exit-code: Exits with non-zero code if tests fail
• -out: Specifies the output file location

Read more in the go-junit-report docs.

Jest

Add the jest-junit reporter package to your project:

npm install --save-dev jest-junit

Configure the reporter in your Jest config:

{
  "reporters": [ "default", "jest-junit" ]
}

Then run Jest normally to generate the report:

jest

For CI environments, you can explicitly specify the reporters:

jest --ci --reporters=default --reporters=jest-junit

Read more in the jest-junit docs.

Mocha

Install the Mocha JUnit reporter either locally:

npm install mocha-junit-reporter --save-dev

or globally:

npm install -g mocha-junit-reporter

Run Mocha with the JUnit reporter:

mocha test --reporter mocha-junit-reporter

By default, this creates test-results.xml in the current directory. You can specify a custom location for the report file in several ways:

Using an environment variable:

MOCHA_FILE=./path_to_your/file.xml mocha test --reporter mocha-junit-reporter

Using reporter options:

mocha test --reporter mocha-junit-reporter --reporter-options mochaFile=./path_to_your/file.xml

Or programmatically:

var mocha = new Mocha({
  reporter: "mocha-junit-reporter",
  reporterOptions: {
    mochaFile: "./path_to_your/file.xml",
  },
});

Read more in the mocha-junit-reporter docs.

Conclusion

Testkubes JUnit report processing and visualization features provide a powerful toolset for managing and analyzing test results. By automatically extracting data from JUnit XML reports and presenting it in both summary and detailed views, Testkube enables teams to gain valuable insights into their test workflows quickly and efficiently.

For more information on related features, check out our Test Insights Reporting documentation.
